Product Description
Voltage Regulator SIP 12V AC/DC 4 Plug (DW-85151000)
Voltage Regulator SIP
for Vespa/​Lambretta
- 4 connections
- 12V AC/DC
A voltage regulator prevents the wiring loom and its connected components from any peaks and overloads in power delivery, so keeping all bulbs intact. It is also responsible for supplying any fitted battery with power and to ensure that it remains loaded when the scooters engine is not running. This particular voltage regulator, with four connections, also serves as a voltage rectifier to convert the alternating current (AC) into 6V/12V direct current (DC) while maintaining a tolerable delivery level. On 6V systems we recommend that the lighting coils be connected in series to optimize power delivery to the scooters lighting system!
Connections:
AC: bridge the two AC connections, the input and output points on the voltage regulator should be connected to keep the voltage constant despite varying loads!
DC: Output to charge the battery.
Earth: Connection to scooters frame/engine casing, voltage regulator/stator plate and wiring loom.
Conclusion: A compact voltage regulator for all 6V/12V scooter models that also require a DC power supply to supplement the AC power produced by the stator/flywheel.
